Blue Sea 7151 Short Stop Circuit Breakers - 10A [7151]
Free Shipping on $199+Regular price $17.99Sale price $17.99 Regular priceUnit price perIn Stock
More info
- Corrosion Resistant Material
- IP 64 Water Resistant Boot
- Push to Reset Only
- Interrupt Capacity: 2,500A @ 28VDC
- Red insulating boot included in retail package
- Amperage: 10A DC
- Maximum Voltage: 28V DC
- Interrupt Capacity: 2500A @ 28V DC
- Minimum Operating Temperature: -10º C
- Maximum Operating Temperature: 60º C
- Screw Terminal Torque: 24 in-lb (2.71 Nm)
- Terminal Stud: #10-32"
- Amperage: 10a
- Box Dimensions: 2"H x 3"W x 7"L WT: 0.2 lbs
- UPC: 632085071516
Blue Sea SystemsBlue Sea 7151 Short Stop Circuit Breakers - 10A [7151]
Code: ORA-68716Brand: Blue Sea SystemsIn StockRegular price $17.99Sale price $17.99 Regular priceUnit price per- Corrosion Resistant Material
- IP 64 Water Resistant Boot
- Push to Reset Only
- Interrupt Capacity: 2,500A @ 28VDC
-
Free Shipping on $199+Regular price $79.99Sale price $79.99 Regular price $0.00Unit price perLow Stock — Only 7 Left
More info
- Color actuator indicates "OFF" position
- "Trip Free" design cannot be held "ON" during fault current condition
- International ON/OFF symbols support vertical or horizontal mounting
- Amperage: 50A AC / 50A DC
- Actuator Style: Flat Rocker
- Poles: 2
- Maximum Voltage: 120V AC / 240V AC / 32V DC
- Circuit Breaker Type: Magnetic Hydraulic - trip free
- Interrupt Capacity: 3000A @ 240V AC / 1500A @ 240V AC[TUV] / 5000A @ 32V DC
- Minimum Operating Temperature: -40° C
- Maximum Operating Temperature: 85° C
- Mounting Screw: #6-32 Stainless Steel
- Mounting Screw Torque: 6 in-lb (0.68 Nm)
- Screw Terminal Torque: 14 in-lb (1.58 Nm)
- Switching Cycles: 10000
- Terminal Screw: #10-32 Stainless Steel
- Weight: 0.38lb (0.17 kg)
- Amperage: 50a
- Box Dimensions: 2"H x 3"W x 5"L WT: 0.4 lbs
- UPC: 632085074173
Blue Sea SystemsBlue Sea 7417 A-Series Flat Rocker Circuit Breaker - Double Pole - 50A [7417]
Code: ORA-65279Brand: Blue Sea SystemsLow Stock — Only 7 LeftRegular price $79.99Sale price $79.99 Regular price $0.00Unit price per- Color actuator indicates "OFF" position
- "Trip Free" design cannot be held "ON" during fault current condition
- International ON/OFF symbols support vertical or horizontal mounting
- Amperage: 50A AC / 50A DC
-
Free Shipping on $199+Regular price $78.99Sale price $78.99 Regular price $0.00Unit price perLow Stock — Only 9 Left
More info
- Color actuator indicates "OFF" position
- "Trip Free" design cannot be held "ON" during fault current condition
- International ON/OFF symbols support vertical or horizontal mounting
- Amperage: 30A AC / 30A DC
- Actuator Style: Raised Rocker
- Poles: 2
- Maximum Voltage: 120V AC / 240V AC / 32V DC
- Circuit Breaker Type: Magnetic Hydraulic - trip free
- Interrupt Capacity: 3000A @ 240V AC / 1500A @ 240V AC[TUV] / 5000A @ 32V DC
- Minimum Operating Temperature: -40° C
- Maximum Operating Temperature: 85° C
- Mounting Screw: #6-32 Stainless Steel
- Mounting Screw Torque: 6 in-lb (0.68 Nm)
- Screw Terminal Torque: 14 in-lb (1.58 Nm)
- Switching Cycles: 10000
- Terminal Screw: #10-32 Stainless Steel
- Weight: 0.38lb (0.17 kg)
- Amperage: 30a
- Box Dimensions: 2"H x 4"W x 5"L WT: 0.35 lbs
- UPC: 632085075743
Blue Sea SystemsBlue Sea 7574 A-Series Raised Rocker Circuit Breaker - Double Pole - 30A [7574]
Code: ORA-65273Brand: Blue Sea SystemsLow Stock — Only 9 LeftRegular price $78.99Sale price $78.99 Regular price $0.00Unit price per- Color actuator indicates "OFF" position
- "Trip Free" design cannot be held "ON" during fault current condition
- International ON/OFF symbols support vertical or horizontal mounting
- Amperage: 30A AC / 30A DC
-
Free Shipping on $199+Regular price $79.99Sale price $79.99 Regular price $0.00Unit price perLow Stock — Only 10 Left
More info
- Color actuator indicates "OFF" position
- "Trip Free" design cannot be held "ON" during fault current condition
- International ON/OFF symbols support vertical or horizontal mounting
- Amperage : 15A AC / 15A DC
- Actuator Style: Flat Rocker
- Poles: 2
- Maximum Voltage: 120V AC / 240V AC / 32V DC
- Circuit Breaker Type: Magnetic Hydraulic - trip free
- Interrupt Capacity: 3000A @ 240V AC / 1500A @ 240V AC[TUV] / 5000A @ 32V DC
- Minimum Operating Temperature: -40° C
- Maximum Operating Temperature: 85° C
- Mounting Screw: #6-32 Stainless Steel
- Mounting Screw Torque: 6 in-lb (0.68 Nm)
- Screw Terminal Torque: 14 in-lb (1.58 Nm)
- Switching Cycles: 10000
- Terminal Screw: #10-32 Stainless Steel
- Weight: 0.38lb (0.17 kg)
- Amperage: 15a
- Box Dimensions: 2"H x 3"W x 5"L WT: 0.4 lbs
- UPC: 632085074111
Blue Sea SystemsBlue Sea 7411 A-Series Flat Rocker Circuit Breaker - Double Pole - 15A [7411]
Code: ORA-65270Brand: Blue Sea SystemsLow Stock — Only 10 LeftRegular price $79.99Sale price $79.99 Regular price $0.00Unit price per- Color actuator indicates "OFF" position
- "Trip Free" design cannot be held "ON" during fault current condition
- International ON/OFF symbols support vertical or horizontal mounting
- Amperage : 15A AC / 15A DC
-
Free Shipping on $199+Regular price $78.99Sale price $78.99 Regular price $0.00Unit price perLow Stock — Only 6 Left
More info
- Color actuator indicates "OFF" position
- "Trip Free" design cannot be held "ON" during fault current condition
- International ON/OFF symbols support vertical or horizontal mounting
- Amperage: 50A AC / 50A DC
- Actuator Style: Raised Rocker
- Poles: 2
- Maximum Voltage: 120V AC / 240V AC / 32V DC
- Circuit Breaker Type: Magnetic Hydraulic - trip free
- Interrupt Capacity: 3000A @ 240V AC / 1500A @ 240V AC[TUV] / 5000A @ 32V DC
- Minimum Operating Temperature: -40° C
- Maximum Operating Temperature: 85° C
- Mounting Screw: #6-32 Stainless Steel
- Mounting Screw Torque: 6 in-lb (0.68 Nm)
- Screw Terminal Torque: 14 in-lb (1.58 Nm)
- Switching Cycles: 10000
- Terminal Screw: #10-32 Stainless Steel
- Weight: 0.38lb (0.17 kg)
- Amperage: 50a
- Box Dimensions: 2"H x 3"W x 5"L WT: 0.35 lbs
- UPC: 632085075774
Blue Sea SystemsBlue Sea 7577 A-Series Raised Rocker Circuit Breaker - Double Pole - 50A [7577]
Code: ORA-65278Brand: Blue Sea SystemsLow Stock — Only 6 LeftRegular price $78.99Sale price $78.99 Regular price $0.00Unit price per- Color actuator indicates "OFF" position
- "Trip Free" design cannot be held "ON" during fault current condition
- International ON/OFF symbols support vertical or horizontal mounting
- Amperage: 50A AC / 50A DC
-
Free Shipping on $199+Regular price $67.99Sale price $67.99 Regular price $0.00Unit price perIn Stock
More info
- Rocker actuator is flush in the "ON" position, eliminating the risk of accidential switching
- Color actuator indicates "OFF" position
- Provides overcurrent protection for inverters, bow thrusters, and windlasses
- Combines switching and circuit protection into a single device
- "Trip Free" - cannot be held closed after trip
- Ignition protectedsafe for installation aboard gasoline powered boats
- Amperage: 50A AC / 50A DC
- Actuator Style: Flat Rocker
- Poles: 1
- Maximum Voltage: 240V AC / 48V DC
- Circuit Breaker Type: Magnetic Hydraulic - trip free
- Terminal Stud Torque: 35 in-lb (3.95 Nm)
- Interrupt Capacity: 3000A @ 120V AC / 3500A @ 240V AC / 5000A @ 32V DC
- Minimum Operating Temperature: -40° C
- Maximum Operating Temperature: 85° C
- Mounting Screw: #6-32 Stainless Steel
- Mounting Screw Torque: 6 in-lb (0.68 Nm)
- Switching Cycles: 10000
- Terminal Stud: 1/4-20 Tin-Plated Brass
- Weight: 0.38lb (0.17 kg)
- Amperage: 50a
- Box Dimensions: 2"H x 2"W x 4"L WT: 0.4 lbs
- UPC: 632085075460
Blue Sea SystemsBlue Sea 7546 C-Series Flat Rocker Circuit Breaker - Single Pole - 50A [7546]
Code: ORA-65286Brand: Blue Sea SystemsIn StockRegular price $67.99Sale price $67.99 Regular price $0.00Unit price per- Rocker actuator is flush in the "ON" position, eliminating the risk of accidential switching
- Color actuator indicates "OFF" position
- Provides overcurrent protection for inverters, bow thrusters, and windlasses
- Combines switching and circuit protection into a single device
-
Free Shipping on $199+Regular price $79.99Sale price $79.99 Regular price $0.00Unit price perLow Stock — Only 9 Left
More info
- Color actuator indicates "OFF" position
- "Trip Free" design cannot be held "ON" during fault current condition
- International ON/OFF symbols support vertical or horizontal mounting
- Amperage : 32A AC / 32A DC
- Actuator Style: Flat Rocker
- Poles: 2
- Maximum Voltage: 120V AC / 240V AC / 32V DC
- Circuit Breaker Type: Magnetic Hydraulic - trip free
- Interrupt Capacity: 3000A @ 240V AC / 1500A @ 240V AC[TUV] / 5000A @ 32V DC
- Minimum Operating Temperature: -40° C
- Maximum Operating Temperature: 85° C
- Mounting Screw: #6-32 Stainless Steel
- Mounting Screw Torque: 6 in-lb (0.68 Nm)
- Screw Terminal Torque: 14 in-lb (1.58 Nm)
- Switching Cycles: 10000
- Terminal Screw: #10-32 Stainless Steel
- Weight: 0.38lb (0.17 kg)
- Amperage: 32a
- Box Dimensions: 2"H x 3"W x 3"L WT: 1 lbs
- UPC: 632085074159
Blue Sea SystemsBlue Sea 7415 A-Series Flat Rocker Circuit Breaker - Double Pole - 32A [7415]
Code: ORA-65276Brand: Blue Sea SystemsLow Stock — Only 9 LeftRegular price $79.99Sale price $79.99 Regular price $0.00Unit price per- Color actuator indicates "OFF" position
- "Trip Free" design cannot be held "ON" during fault current condition
- International ON/OFF symbols support vertical or horizontal mounting
- Amperage : 32A AC / 32A DC
-
Free Shipping on $199+Regular price $30.99Sale price $30.99 Regular price $0.00Unit price perIn Stock
More info
- Meets American Boat and Yacht Council (ABYC) standards
- The industry standard circuit breaker for Blue Sea Systems" electrical panels
- Combines swtiching and circuit protection into a single device
- "Trip Free" design cannot be held "ON" during fault current condition
- Amperage: 2.5A AC / 2.5A DC
- Color: White
- Actuator Style: Toggle
- Poles: 1
- Maximum Voltage: 250V AC / 65V DC
- Circuit Breaker Type: Magnetic Hydraulic - trip free
- Interrupt Capacity: 3000A @ 120V AC / 1500A @ 250V AC [TUV] / 3000A @ 250V AC [UL 1077] / 7500A @ 65V DC
- Minimum Operating Temperature: -40° C
- Maximum Operating Temperature: 85° C
- Mounting Screw: #6-32 Stainless Steel
- Mounting Screw Torque: 6 in-lb (0.68 Nm)
- Screw Terminal Torque: 14 in-lb (1.58 Nm)
- Switching Cycles: 10000
- Terminal Screw: #10-32 Stainless Steel
- Weight: 0.17lb (0.08 kg)
- Amperage: 2.5a
- Box Dimensions: 1"H x 3"W x 5"L WT: 0.4 lbs
- UPC: 632085071974
Blue Sea SystemsBlue Sea 7197 A-Series White Toggle Circuit Breaker - Single Pole 2.5A [7197]
Code: ORA-64359Brand: Blue Sea SystemsIn StockRegular price $30.99Sale price $30.99 Regular price $0.00Unit price per- Meets American Boat and Yacht Council (ABYC) standards
- The industry standard circuit breaker for Blue Sea Systems" electrical panels
- Combines swtiching and circuit protection into a single device
- "Trip Free" design cannot be held "ON" during fault current condition
-
Free Shipping on $199+Regular price $40.99Sale price $40.99 Regular price $0.00Unit price perLow Stock — Only 9 Left
More info
- Rocker actuator is flush in the "ON" position, eliminating the risk of accidential switching
- Color actuator indicates "OFF" position
- "Trip Free" design cannot be held "ON" during fault current condition
- 2 different actuator styles available
- Prevents accidental switching of 24 hour circuits
- International ON/OFF symbols support vertical or horizontal mounting
- Amperage: 2.5A DC / 2.5A AC
- Actuator Style: Flat Rocker
- Poles: 1
- Max Voltage:250V AC / 32V DC
- Circuit Breaker Type: Magnetic Hydraulic - Trip Free
- Interrupt Capacity: 3000A @ 125V AC / 1500A @ 250V AC / 5000A @ 32V DC
- Minimum Operating Temperature: -40° C
- Maximum Operating Temperature: 85° C
- Mounting Screw: #6-32 Stainless Steel
- Mounting Screw Torque: 6 in-lb (0.68 Nm)
- Screw Terminal Torque 14 in-lb (1.58 Nm)
- Switching Cycles: 10000
- Terminal Screw: #10-32 Stainless Steel
- Weight: 0.21lb (0.1 kg)
- Amperage: 2.5a
- Box Dimensions: 1"H x 3"W x 5"L WT: 0.2 lbs
- UPC: 632085073992
Blue Sea SystemsBlue Sea 7399 A-Series Flat Rocker Circuit Breaker - Single Pole - 2.5A [7399]
Code: ORA-64361Brand: Blue Sea SystemsLow Stock — Only 9 LeftRegular price $40.99Sale price $40.99 Regular price $0.00Unit price per- Rocker actuator is flush in the "ON" position, eliminating the risk of accidential switching
- Color actuator indicates "OFF" position
- "Trip Free" design cannot be held "ON" during fault current condition
- 2 different actuator styles available
-
Free Shipping on $199+Regular price $11.99Sale price $11.99 Regular price $0.00Unit price perIn Stock
More info
- Branch circuit breakers (can also be used for 24-hour circuit protection)
- Compact design enables high density circuit protection configurations
- Push-to-reset operation
- "Trip Free" design cannot be held "ON" during fault current condition
- Ignition protected - Safe for installation aboard gasoline powered boats
- Optional Push Button Waterproof Boot protects circuit breaker in wet environments, replaces dress nut mounting on circuit breakers and resists discoloration and cracking
- Amperage: 15A
- Maximum Voltage: 32V DC
- Mounting: Panel Mount 3/8-27 UNS
- Circuit Breaker Type: Thermal trip, manual push-button reset only
- Terminal Type: #8 Screw
- Interrupt Capacity: 3000A @ 14.7V / 2500A @ 28V
- Minimum Operating Temperature: -10° C
- Maximum Operating Temperature: 60° C
- Screw Terminal Torque: 6 in-lb (0.68 Nm)
- Amperage: 15a
- Box Dimensions: 1"H x 3"W x 4"L WT: 0.2 lbs
- UPC: 632085021337
Blue Sea SystemsBlue Sea Push Button Reset Only Screw Terminal Circuit Breaker - 15 Amps [2133]
Code: ORA-62203Brand: Blue Sea SystemsIn StockRegular price $11.99Sale price $11.99 Regular price $0.00Unit price per- Branch circuit breakers (can also be used for 24-hour circuit protection)
- Compact design enables high density circuit protection configurations
- Push-to-reset operation
- "Trip Free" design cannot be held "ON" during fault current condition
-
Free Shipping on $199+Regular price $11.99Sale price $11.99 Regular price $0.00Unit price perIn Stock
More info
- Branch circuit breakers (can also be used for 24-hour circuit protection)
- Compact design enables high density circuit protection configurations
- Push-to-reset operation
- "Trip Free" design cannot be held "ON" during fault current condition
- Ignition protected - Safe for installation aboard gasoline powered boats
- Optional Push Button Waterproof Boot protects circuit breaker in wet environments, replaces dress nut mounting on circuit breakers and resists discoloration and cracking
- Amperage: 5A
- Maximum Voltage: 32V DC
- Mounting: Panel Mount 3/8-27 UNS
- Circuit Breaker Type: Thermal trip, manual push-button reset only
- Terminal Type: #8 Screw
- Interrupt Capacity: 3000A @ 14.7V / 2500A @ 28V
- Minimum Operating Temperature: -10° C
- Maximum Operating Temperature: 60° C
- Screw Terminal Torque: 6 in-lb (0.68 Nm)
- Amperage: 5a
- Box Dimensions: 1"H x 3"W x 5"L WT: 0.1 lbs
- UPC: 632085021306
Blue Sea SystemsBlue Sea Push Button Reset Only Screw Terminal Circuit Breaker - 5 Amps [2130]
Code: ORA-62200Brand: Blue Sea SystemsIn StockRegular price $11.99Sale price $11.99 Regular price $0.00Unit price per- Branch circuit breakers (can also be used for 24-hour circuit protection)
- Compact design enables high density circuit protection configurations
- Push-to-reset operation
- "Trip Free" design cannot be held "ON" during fault current condition
-
Free Shipping on $199+Regular price $11.99Sale price $11.99 Regular price $0.00Unit price perIn Stock
More info
- Branch circuit breakers (can also be used for 24-hour circuit protection)
- Compact design enables high density circuit protection configurations
- Push-to-reset operation
- "Trip Free" design cannot be held "ON" during fault current condition
- Ignition protected - Safe for installation aboard gasoline powered boats
- Optional Push Button Waterproof Boot protects circuit breaker in wet environments, replaces dress nut mounting on circuit breakers and resists discoloration and cracking
- Amperage: 3A
- Maximum Voltage: 32V DC
- Mounting: Panel Mount 3/8-27 UNS
- Circuit Breaker Type: Thermal trip, manual push-button reset only
- Terminal Type: #8 Screw
- Interrupt Capacity: 3000A @ 14.7V / 2500A @ 28V
- Minimum Operating Temperature: -10° C
- Maximum Operating Temperature: 60° C
- Screw Terminal Torque: 6 in-lb (0.68 Nm)
- Amperage: 3a
- Box Dimensions: 1"H x 3"W x 5"L WT: 0.1 lbs
- UPC: 632085021290
Blue Sea SystemsBlue Sea Push Button Reset Only Screw Terminal Circuit Breaker - 3 Amps [2129]
Code: ORA-63008Brand: Blue Sea SystemsIn StockRegular price $11.99Sale price $11.99 Regular price $0.00Unit price per- Branch circuit breakers (can also be used for 24-hour circuit protection)
- Compact design enables high density circuit protection configurations
- Push-to-reset operation
- "Trip Free" design cannot be held "ON" during fault current condition
-
Free Shipping on $199+Regular price $11.99Sale price $11.99 Regular price $0.00Unit price perIn Stock
More info
- Branch circuit breakers (can also be used for 24-hour circuit protection)
- Compact design enables high density circuit protection configurations
- Push-to-reset operation
- "Trip Free" design cannot be held "ON" during fault current condition
- Ignition protected - Safe for installation aboard gasoline powered boats
- Optional Push Button Waterproof Boot protects circuit breaker in wet environments, replaces dress nut mounting on circuit breakers and resists discoloration and cracking
- Amperage: 40A
- Maximum Voltage: 32V DC
- Mounting: Panel Mount 3/8-27 UNS
- Circuit Breaker Type: Thermal trip, manual push-button reset only
- Terminal Type: #8 Screw
- Interrupt Capacity: 3000A @ 14.7V / 2500A @ 28V
- Minimum Operating Temperature: -10° C
- Maximum Operating Temperature: 60° C
- Screw Terminal Torque: 6 in-lb (0.68 Nm)
- Amperage: 40a
- Box Dimensions: 1"H x 3"W x 5"L WT: 0.1 lbs
- UPC: 632085021375
Blue Sea SystemsBlue Sea Push Button Reset Only Screw Terminal Circuit Breaker - 40 Amps [2137]
Code: ORA-63012Brand: Blue Sea SystemsIn StockRegular price $11.99Sale price $11.99 Regular price $0.00Unit price per- Branch circuit breakers (can also be used for 24-hour circuit protection)
- Compact design enables high density circuit protection configurations
- Push-to-reset operation
- "Trip Free" design cannot be held "ON" during fault current condition
-
Free Shipping on $199+Regular price $11.99Sale price $11.99 Regular price $0.00Unit price perIn Stock
More info
- Branch circuit breakers (can also be used for 24-hour circuit protection)
- Compact design enables high density circuit protection configurations
- Push-to-reset operation
- "Trip Free" design cannot be held "ON" during fault current condition
- Ignition protected - Safe for installation aboard gasoline powered boats
- Optional Push Button Waterproof Boot protects circuit breaker in wet environments, replaces dress nut mounting on circuit breakers and resists discoloration and cracking
- Amperage: 20A
- Maximum Voltage: 32V DC
- Mounting: Panel Mount 3/8-27 UNS
- Circuit Breaker Type: Thermal trip, manual push-button reset only
- Terminal Type: #8 Screw
- Interrupt Capacity: 3000A @ 14.7V / 2500A @ 28V
- Minimum Operating Temperature: -10° C
- Maximum Operating Temperature: 60° C
- Screw Terminal Torque: 6 in-lb (0.68 Nm)
- Amperage: 20a
- Box Dimensions: 1"H x 3"W x 5"L WT: 0.1 lbs
- UPC: 632085021344
Blue Sea SystemsBlue Sea Push Button Reset Only Screw Terminal Circuit Breaker - 20 Amps [2134]
Code: ORA-62204Brand: Blue Sea SystemsIn StockRegular price $11.99Sale price $11.99 Regular price $0.00Unit price per- Branch circuit breakers (can also be used for 24-hour circuit protection)
- Compact design enables high density circuit protection configurations
- Push-to-reset operation
- "Trip Free" design cannot be held "ON" during fault current condition
-
Free Shipping on $199+Regular price $11.99Sale price $11.99 Regular price $0.00Unit price perLow Stock — Only 4 Left
More info
- Branch circuit breakers (can also be used for 24-hour circuit protection)
- Compact design enables high density circuit protection configurations
- Push-to-reset operation
- "Trip Free" design cannot be held "ON" during fault current condition
- Ignition protected - Safe for installation aboard gasoline powered boats
- Optional Push Button Waterproof Boot protects circuit breaker in wet environments, replaces dress nut mounting on circuit breakers and resists discoloration and cracking
- Amperage: 30A
- Maximum Voltage: 32V DC
- Mounting: Panel Mount 3/8-27 UNS
- Circuit Breaker Type: Thermal trip, manual push-button reset only
- Terminal Type: #8 Screw
- Interrupt Capacity: 3000A @ 14.7V / 2500A @ 28V
- Minimum Operating Temperature: -10° C
- Maximum Operating Temperature: 60° C
- Screw Terminal Torque: 6 in-lb (0.68 Nm)
- Amperage: 30a
- Box Dimensions: 1"H x 3"W x 5"L WT: 0.1 lbs
- UPC: 632085021368
Blue Sea SystemsBlue Sea Push Button Reset Only Screw Terminal Circuit Breaker - 30 Amps [2136]
Code: ORA-63011Brand: Blue Sea SystemsLow Stock — Only 4 LeftRegular price $11.99Sale price $11.99 Regular price $0.00Unit price per- Branch circuit breakers (can also be used for 24-hour circuit protection)
- Compact design enables high density circuit protection configurations
- Push-to-reset operation
- "Trip Free" design cannot be held "ON" during fault current condition
-
Free Shipping on $199+Regular price $11.99Sale price $11.99 Regular price $0.00Unit price perIn Stock
More info
- Branch circuit breakers (can also be used for 24-hour circuit protection)
- Compact design enables high density circuit protection configurations
- Push-to-reset operation
- "Trip Free" design cannot be held "ON" during fault current condition
- Ignition protected - Safe for installation aboard gasoline powered boats
- Optional Push Button Waterproof Boot protects circuit breaker in wet environments, replaces dress nut mounting on circuit breakers and resists discoloration and cracking
- Amperage: 7A
- Maximum Voltage: 32V DC
- Mounting: Panel Mount 3/8-27 UNS
- Circuit Breaker Type: Thermal trip, manual push-button reset only
- Terminal Type: #8 Screw
- Interrupt Capacity: 3000A @ 14.7V / 2500A @ 28V
- Minimum Operating Temperature: -10° C
- Maximum Operating Temperature: 60° C
- Screw Terminal Torque: 6 in-lb (0.68 Nm)
- Amperage: 7a
- Box Dimensions: 1"H x 3"W x 5"L WT: 0.1 lbs
- UPC: 632085021313
Blue Sea SystemsBlue Sea Push Button Reset Only Screw Terminal Circuit Breaker - 7 Amps [2131]
Code: ORA-63009Brand: Blue Sea SystemsIn StockRegular price $11.99Sale price $11.99 Regular price $0.00Unit price per- Branch circuit breakers (can also be used for 24-hour circuit protection)
- Compact design enables high density circuit protection configurations
- Push-to-reset operation
- "Trip Free" design cannot be held "ON" during fault current condition
-
Free Shipping on $199+Regular price $11.99Sale price $11.99 Regular price $0.00Unit price perIn Stock
More info
- Branch circuit breakers (can also be used for 24-hour circuit protection)
- Compact design enables high density circuit protection configurations
- Push-to-reset operation
- "Trip Free" design cannot be held "ON" during fault current condition
- Ignition protected - Safe for installation aboard gasoline powered boats
- Optional Push Button Waterproof Boot protects circuit breaker in wet environments, replaces dress nut mounting on circuit breakers and resists discoloration and cracking
- Amperage: 25A
- Maximum Voltage: 32V DC
- Mounting: Panel Mount 3/8-27 UNS
- Circuit Breaker Type: Thermal trip, manual push-button reset only
- Terminal Type: #8 Screw
- Interrupt Capacity: 3000A @ 14.7V / 2500A @ 28V
- Minimum Operating Temperature: -10° C
- Maximum Operating Temperature: 60° C
- Screw Terminal Torque: 6 in-lb (0.68 Nm)
- Amperage: 25a
- Box Dimensions: 1"H x 3"W x 5"L WT: 0.1 lbs
- UPC: 632085021351
Blue Sea SystemsBlue Sea Push Button Reset Only Screw Terminal Circuit Breaker - 25 Amps [2135]
Code: ORA-63010Brand: Blue Sea SystemsIn StockRegular price $11.99Sale price $11.99 Regular price $0.00Unit price per- Branch circuit breakers (can also be used for 24-hour circuit protection)
- Compact design enables high density circuit protection configurations
- Push-to-reset operation
- "Trip Free" design cannot be held "ON" during fault current condition
-
BEP Marine
BEP Circuit Breaker Module [707]
Free Shipping on $199+Regular price $219.99Sale price $219.99 Regular price $0.00Unit price perLow Stock — Only 3 Left
More info
Circuit Breaker ModuleThe 707 Circuit Breaker Module offers provision for three circuit breakers ideal for medium duty loads, like waste treatment systems and electric toilets. It is designed to separate these loadings from the main DC panel, thus avoiding unnecessary voltage spikes. Contained in the Contour lock double module, it...BEP MarineBEP Circuit Breaker Module [707]
Code: ORA-58719Brand: BEP MarineLow Stock — Only 3 LeftRegular price $219.99Sale price $219.99 Regular price $0.00Unit price perCircuit Breaker ModuleThe 707 Circuit Breaker Module offers provision for three circuit breakers ideal for medium duty loads, like waste...
-
BEP Marine
BEP Heavy Duty CB Module - 80A [705-80A]
Free Shipping on $199+Regular price $193.99Sale price $193.99 Regular price $0.00Unit price perLow Stock — Only 2 Left
More info
- Allows switchable protection for heavy duty circuits like windlasses or davit winches
- Modular sizing with contour lock molding allows easy grouping
- Amperage: 80a
- Box Dimensions: 3"H x 4"W x 9"L WT: 0.6 lbs
- UPC: 870216010038
BEP MarineBEP Heavy Duty CB Module - 80A [705-80A]
Code: ORA-58721Brand: BEP MarineLow Stock — Only 2 LeftRegular price $193.99Sale price $193.99 Regular price $0.00Unit price per- Allows switchable protection for heavy duty circuits like windlasses or davit winches
- Modular sizing with contour lock molding allows easy grouping
- Amperage: 80a
- Box Dimensions: 3"H x 4"W x 9"L WT: 0.6 lbs
-
Free Shipping on $199+Regular price $105.99Sale price $105.99 Regular price $0.00Unit price perIn Stock
More info
- Quick connect clips allow circuit breakers to snap easily into place
- Tin-plated copper busses and screw terminals
- Clear insulating cover with square format label recesses, satisfies ABYC/USCG insulation requirements
- Easy to open clip on cover
- Breakouts allow wire access in two directions
- Accepts ring terminals
- Optional push button waterproof boots or dress nuts can be installed over cover
- Amperage: 100/32a
- Box Dimensions: 3"H x 5"W x 11"L WT: 0.9 lbs
- UPC: 632085050528
Blue Sea SystemsBlue Sea 5052 ST CLB Circuit Breaker Block - 6 Position w/Negative Bus [5052]
Code: ORA-51811Brand: Blue Sea SystemsIn StockRegular price $105.99Sale price $105.99 Regular price $0.00Unit price per- Quick connect clips allow circuit breakers to snap easily into place
- Tin-plated copper busses and screw terminals
- Clear insulating cover with square format label recesses, satisfies ABYC/USCG insulation requirements
- Easy to open clip on cover
-
Blue Sea Systems
Blue Sea 5050 ST CLB Circuit Breaker Block - 6 Position [5050]
Free Shipping on $199+Regular price $82.99Sale price $82.99 Regular price $0.00Unit price perLow Stock — Only 4 Left
More info
- Quick connect clips allow circuit breakers to snap easily into place
- Tin-plated copper busses and screw terminals
- Clear insulating cover with square format label recesses, satisfies ABYC/USCG insulation requirements
- Easy to open clip on cover
- Breakouts allow wire access in two directions
- Accepts ring terminals
- Optional push button waterproof boots or dress nuts can be installed over cover
- Amperage: 32/40a
- Box Dimensions: 3"H x 5"W x 11"L WT: 0.8 lbs
- UPC: 632085050504
Blue Sea SystemsBlue Sea 5050 ST CLB Circuit Breaker Block - 6 Position [5050]
Code: ORA-51809Brand: Blue Sea SystemsLow Stock — Only 4 LeftRegular price $82.99Sale price $82.99 Regular price $0.00Unit price per- Quick connect clips allow circuit breakers to snap easily into place
- Tin-plated copper busses and screw terminals
- Clear insulating cover with square format label recesses, satisfies ABYC/USCG insulation requirements
- Easy to open clip on cover
-
Free Shipping on $199+Regular price $181.99Sale price $181.99 Regular price $0.00Unit price perIn Stock
More info
- Quick connect clips allow circuit breakers to snap easily into place
- Tin-plated copper busses and screw terminals
- Clear insulating cover with square format label recesses, satisfies ABYC/USCG insulation requirements
- Easy to open clip on cover
- Breakouts allow wire access in two directions
- Accepts ring terminals
- Optional push button waterproof boots or dress nuts can be installed over cover
- Amperage: 100/32a
- Box Dimensions: 3"H x 5"W x 15"L WT: 1.5 lbs
- UPC: 632085050542
Blue Sea SystemsBlue Sea 5054 ST CLB Circuit Breaker Block - 12 Position w/Negative Bus [5054]
Code: ORA-51812Brand: Blue Sea SystemsIn StockRegular price $181.99Sale price $181.99 Regular price $0.00Unit price per- Quick connect clips allow circuit breakers to snap easily into place
- Tin-plated copper busses and screw terminals
- Clear insulating cover with square format label recesses, satisfies ABYC/USCG insulation requirements
- Easy to open clip on cover
-
Blue Sea Systems
Blue Sea 5051 ST CLB Circuit Breaker Block - 12 Position [5051]
Free Shipping on $199+Regular price $135.99Sale price $135.99 Regular price $0.00Unit price perLow Stock — Only 9 Left
More info
- Quick connect clips allow circuit breakers to snap easily into place
- Tin-plated copper busses and screw terminals
- Clear insulating cover with square format label recesses, satisfies ABYC/USCG insulation requirements
- Easy to open clip on cover
- Breakouts allow wire access in two directions
- Accepts ring terminals
- Optional push button waterproof boots or dress nuts can be installed over cover
- Amperage: 32/40a
- Box Dimensions: 3"H x 5"W x 18"L WT: 1.3 lbs
- UPC: 632085050511
Blue Sea SystemsBlue Sea 5051 ST CLB Circuit Breaker Block - 12 Position [5051]
Code: ORA-51810Brand: Blue Sea SystemsLow Stock — Only 9 LeftRegular price $135.99Sale price $135.99 Regular price $0.00Unit price per- Quick connect clips allow circuit breakers to snap easily into place
- Tin-plated copper busses and screw terminals
- Clear insulating cover with square format label recesses, satisfies ABYC/USCG insulation requirements
- Easy to open clip on cover
-
Blue Sea Systems
Blue Sea 7088 120 Amp Circuit Breaker Panel Mount 285 Series [7088]
Free Shipping on $199+Regular price $89.99Sale price $89.99 Regular price $0.00Unit price perLow Stock — Only 7 Left
More info
- Drop in replacement for 185-Series Circuit Breakers
- Visible reset lever shows open condition
- Amperage: 120a
- Box Dimensions: 2"H x 4"W x 8"L WT: 0.3 lbs
- UPC: 632085070885
Blue Sea SystemsBlue Sea 7088 120 Amp Circuit Breaker Panel Mount 285 Series [7088]
Code: ORA-40628Brand: Blue Sea SystemsLow Stock — Only 7 LeftRegular price $89.99Sale price $89.99 Regular price $0.00Unit price per- Drop in replacement for 185-Series Circuit Breakers
- Visible reset lever shows open condition
- Amperage: 120a
- Box Dimensions: 2"H x 4"W x 8"L WT: 0.3 lbs
