Victron Energy
Victron Energy Orion-TR Smart 24/12-30 30A (360W) Isolated DC-DC or Power Supply [ORI241236120]
Save $43.05
Free Shipping on $114+Regular price $243.95Sale price $243.95 Regular price $287.00Unit price perSale: $43.05 offLow Stock — Only 5 Left
More info
- Any Bluetooth-enabled smartphone, tablet, or other device can be used to monitor, change settings, and update the charger when new software features become available
- Instant Readout: The VictronConnect App can display key data, including warnings and alarms, on the device list page without the need to connect to the product
- Battery charge algorithm (configurable) or fixed output.
- Smart Alternator Compatibility: engine running detection mechanism
- For lithium batteries, the absorption time is fixed; the default is 2 hours
- Alternatively, a fixed output voltage can be chosen
- Input Voltage Range: 20-35 V
- Under Voltage Shut Down: 14 V
- Under Voltage Restart: 15 V
- Nominal Output Voltage: 12.2 V
- Output Voltage Adjust Range: 10-15 V
- Output Voltage Tolerance: +/- 0,2 V
- Output Noise: 2 mV rms
- Cont. Output Current at Nominal Output Voltage and 40 Degrees C: 30 A
- Maximum Output Current (10 S) at Nominal Output Voltage minus 20%: 45 A
- Short Circuit Output Current: 60 A
- Cont. Output Power at 25 Degrees C: 430 W
- Cont. Output Power at 40 Degrees C: 360 W
- Efficiency: 88 %
- No Load Input Current (2): < 100 mA
- Standby Current: Less than 1A
- Can Be Used as Power Supply: Yes, output voltage can be set with Bluetooth
- Galvanic Isolation: 200 VDC between input, output, and case
- Operating Temperature Range -20 to +55 °C (derate 3 % per °C above 40 °C)
- Humidity: Max. 95 % non-condensing
- DC Connection: Screw terminals
- Maximum Cable Cross-Section: 16 mm² AWG6
- Weight: 1,6 kg (3.5 lb)
- Dimensions (H x W x D):130 x 186 x 70 mm (5.1 x 7.3 x 2.8 inch)
- Protection Category IP43 (electronic components), IP22 (connection area)
- Safety Standards: EN 60950
- Emission/Immunity Standards: EN 61000-6-3, EN 55014-1 / EN 61000-6-2, EN 61000-6-1, EN 55014-2
- Automotive Directive Standards: ECE R10-5
- Charger Input - Voltage: 24v
- Charger Output - Amps: 30a
- Charger Output Voltage: 12v
- Box Dimensions: 4"H x 6"W x 9"L WT: 4.4 lbs
- UPC: 8719076047711
Victron EnergyVictron Energy Orion-TR Smart 24/12-30 30A (360W) Isolated DC-DC or Power Supply [ORI241236120]
Code: ORA-84225Brand: Victron EnergyLow Stock — Only 5 LeftRegular price $243.95Sale price $243.95 Regular price $287.00Unit price perSale: $43.05 off- Battery charge algorithm (configurable) or fixed output.
- Smart Alternator Compatibility: engine running detection mechanism
- For lithium batteries, the absorption time is fixed; the default is 2 hours
- Alternatively, a fixed output voltage can be chosen
-
Victron Energy
Victron Orion-TR Smart DC-DC 12/24-15 15A (360W) Isolated Charger or Power Supply [ORI122436120]
Save $43.05
Free Shipping on $114+Regular price $243.95Sale price $243.95 Regular price $287.00Unit price perSale: $43.05 offLow Stock — Only 6 Left
More info
- Any Bluetooth-enabled smartphone, tablet, or other device can be used to monitor, change settings, and update the charger when new software features become available
- Instant Readout: The VictronConnect App can display key data, including warnings and alarms, on the device list page without the need to connect to the product
- Battery charge algorithm (configurable) or fixed output.
- Smart Alternator Compatibility: engine running detection mechanism
- For lithium batteries, the absorption time is fixed; the default is 2 hours
- Alternatively, a fixed output voltage can be chosen
- Input Voltage Range: 10-17 V
- Under Voltage Shut Down: 7 V
- Under Voltage Restart: 7.5 V
- Nominal Output Voltage: 24.2 V
- Output Voltage Adjust Range: 20-36 V
- Output Voltage Tolerance: +/- 0,2 V
- Output Noise: 2 mV rms
- Cont. Output Current at Nominal Output Voltage and 40 Degrees C: 15 A
- Maximum Output Current (10 S) at Nominal Output Voltage minus 20%: 25 A
- Short Circuit Output Current: 40 A
- Cont. Output Power at 25 Degrees C: 430 W
- Cont. Output Power at 40 Degrees C: 360 W
- Efficiency: 88 %
- No Load Input Current (2): < 100 mA
- Standby Current: Less than 1A
- Can Be Used as Power Supply: Yes, output voltage can be set with Bluetooth
- Galvanic Isolation: 200 VDC between input, output, and case
- Operating Temperature Range -20 to +55 °C (derate 3 % per °C above 40 °C)
- Humidity: Max. 95 % non-condensing
- DC Connection: Screw terminals
- Maximum Cable Cross-Section: 16 mm² AWG6
- Weight: 1,8 kg (3 lb)
- Dimensions (H x W x D):130 x 186 x 70 mm (5.1 x 7.3 x 2.8 inch)
- Protection Category IP43 (electronic components), IP22 (connection area)
- Safety Standards: EN 60950
- Emission/Immunity Standards: EN 61000-6-3, EN 55014-1 / EN 61000-6-2, EN 61000-6-1, EN 55014-2
- Automotive Directive Standards: ECE R10-5
- Portable: No
- Charging Banks: 1
- Charger Output Voltage: 24v
- Charger Output - Amps: 15a
- Charger Input - Voltage: 12v
- Box Dimensions: 4"H x 5"W x 8"L WT: 4.4 lbs
- UPC: 8719076047704
Victron EnergyVictron Orion-TR Smart DC-DC 12/24-15 15A (360W) Isolated Charger or Power Supply [ORI122436120]
Code: ORA-84227Brand: Victron EnergyLow Stock — Only 6 LeftRegular price $243.95Sale price $243.95 Regular price $287.00Unit price perSale: $43.05 off- Battery charge algorithm (configurable) or fixed output.
- Smart Alternator Compatibility: engine running detection mechanism
- For lithium batteries, the absorption time is fixed; the default is 2 hours
- Alternatively, a fixed output voltage can be chosen
-
Save $35.55
Free Shipping on $114+Regular price $201.45Sale price $201.45 Regular price $237.00Unit price perSale: $35.55 offLow Stock — Only 9 Left
More info
- Input Voltage Range: 10-17 V
- Under Voltage Shut Down: 7 V
- Under Voltage Restart: 7.5 V
- Nominal Output Voltage: 12.2 V
- Output Voltage Adjust Range: 10-15 V
- Output Voltage Tolerance: +/- 0,2 V
- Output Noise: 2 mV rms
- Cont. Output Current at Nominal Output Voltage and 40 Degrees C: 30 A
- Maximum output current (10 s) at nominal output voltage minus 20%: 40 A
- Short Circuit Output Current: 60 A
- Cont. Output Power at 25 Degrees C: 430 W
- Cont. Output Power at 40 Degrees C: 360 W
- Efficiency: 87 %
- No Load Input Current (2): < 80 mA
- Current Consumption: < 200uA when disabled via its remote port
- Galvanic Isolation: 200 VDC between input, output, and case
- Operating Temperature Range: -20 to +55 Degrees C (derate 3 % per °C above 40 °C)
- Humidity: Max. 95 % non-condensing
- DC Connection: Screw terminals
- Maximum Cable Cross-Section: 16 mm² AWG6
- Weight: 1.8 kg (4 lb)
- Dimensions (H x W x D): 130 x 186 x 80 mm (5.1 x 7.3 x 3.2 inch)
- Safety Standards: EN 60950
- Immunity Standards: EN 61000-6-2, EN 61000-6-1, EN 55014-2
- Automotive Directive Standards: ECE R10-5
- Charger Input - Voltage: 12v
- Charger Output - Amps: 30a
- Charger Output Voltage: 12v
- Box Dimensions: 4"H x 5"W x 8"L WT: 4.2 lbs
- UPC: 8719076038825
Victron EnergyVictron Orion-TR DC-DC Converter - 12 VDC to 12 VDC - 30AMP Isolated [ORI121240110]
Code: ORA-82870Brand: Victron EnergyLow Stock — Only 9 LeftRegular price $201.45Sale price $201.45 Regular price $237.00Unit price perSale: $35.55 off- Input Voltage Range: 10-17 V
- Under Voltage Shut Down: 7 V
- Under Voltage Restart: 7.5 V
- Nominal Output Voltage: 12.2 V
-
Save $52.20
Free Shipping on $114+Regular price $295.80Sale price $295.80 Regular price $348.00Unit price perSale: $52.20 offIn Stock
More info
- Wide input voltage range With 15 to 40 Volts input range, a stable output is ensured during surges or sags due to other equipment connected to same battery.
- Protected against overheating It can be used in a hot environment such as a machine room.
Victron EnergyVictron Orion IP67 DC-DC Converter - 24 VDC to 12 VDC - 100AMP [ORI241221226]
Code: ORA-82861Brand: Victron EnergyIn StockRegular price $295.80Sale price $295.80 Regular price $348.00Unit price perSale: $52.20 off- Protected against overheating It can be used in a hot environment such as a machine room.
-
Save $20.10
Free Shipping on $114+Regular price $113.90Sale price $113.90 Regular price $134.00Unit price perSale: $20.10 offLow Stock — Only 8 Left
More info
- Input Voltage Range: 8-17 V
- Under Voltage Shut Down: 7 V
- Under Voltage Restart: 7.5 V
- Nominal Output Voltage: 12.2 V
- Output Voltage Adjust Range: 10-15 V
- Output Voltage Tolerance: +/- 0,2 V
- Output Noise: 2 mV rms
- Cont. Output Current at Nominal Output Voltage and 40 Degrees C: 18 A
- Maximum Output Current (10 S) at Nominal Output Voltage: 25 A
- Short Circuit Output Current: 40 A
- Cont. Output Power at 25 Degrees C: 280 W
- Cont. Output Power at 40 Degrees C: 220 W
- Efficiency: 87 %
- No Load Input Current (2): < 80 mA
- Current Consumption: < 200uA when disabled via its remote port
- Galvanic Isolation: 200 VDC between input, output, and case
- Operating Temperature Range: -20 to +55 Degrees C (derate 3 % per °C above 40 °C)
- Humidity: Max. 95 % non-condensing
- DC Connection: Screw terminals
- Maximum Cable Cross-Section: 16 mm² AWG6
- Weight: 1.3 kg (3 lb)
- Dimensions (H x W x D): 130 x 186 x 70 mm (5.1 x 7.3 x 2.8 inch)
- Safety Standards: EN 60950
- Immunity Standards: EN 61000-6-3, EN 61000-6-1, EN 55014-2
- Automotive Directive Standards: ECE R10-5
- Charger Input - Voltage: 12v
- Charger Output - Amps: 18a
- Charger Output Voltage: 12v
- Box Dimensions: 4"H x 5"W x 8"L WT: 2.8 lbs
- UPC: 8719076035237
Victron EnergyVictron Orion-TR DC-DC Converter - 12 VDC to 12 VDC - 18AMP Isolated [ORI121222110]
Code: ORA-82868Brand: Victron EnergyLow Stock — Only 8 LeftRegular price $113.90Sale price $113.90 Regular price $134.00Unit price perSale: $20.10 off- Input Voltage Range: 8-17 V
- Under Voltage Shut Down: 7 V
- Under Voltage Restart: 7.5 V
- Nominal Output Voltage: 12.2 V
-
Save $20.10
Free Shipping on $114+Regular price $113.90Sale price $113.90 Regular price $134.00Unit price perSale: $20.10 offLow Stock — Only 6 Left
More info
- Input Voltage Range: 16-35 V
- Under Voltage Shut Down: 14 V
- Under Voltage Restart: 15 V
- Nominal Output Voltage: 12.2 V
- Output Voltage Adjust Range: 10-15 V
- Output Voltage Tolerance: +/- 0,2 V
- Output Noise: 2 mV rms
- Cont. Output Current at Nominal Output Voltage and 40 Degrees C: 20 A
- Maximum Output Current (10 S) at Nominal Output Voltage: 25 A
- Short Circuit Output Current: 50 A
- Cont. Output Power at 25 Degrees C: 300 W
- Cont. Output Power at 40 Degrees C: 240 W
- Efficiency: 88 %
- No Load Input Current (2): < 100 mA
- Current Consumption: < 200uA when disabled via its remote port
- Galvanic Isolation: 200 VDC between input, output, and case
- Operating Temperature Range: -20 to +55 Degrees C (derate 3 % per °C above 40 °C)
- Humidity: Max. 95 % non-condensing
- DC Connection: Screw terminals
- Maximum Cable Cross-Section: 16 mm² AWG6
- Weight: 1.3 kg (3 lb)
- Dimensions (H x W x D): 130 x 186 x 70 mm (5.1 x 7.3 x 2.8 inch)
- Safety Standards: EN 60950
- Immunity Standards: EN 61000-6-2, EN 61000-6-1, EN 55014-2
- Automotive Directive Standards: ECE R10-5
- Charger Input - Voltage: 24v
- Charger Output - Amps: 20a
- Charger Output Voltage: 12v
- Box Dimensions: 4"H x 5"W x 8"L WT: 2.9 lbs
- UPC: 8719076035251
Victron EnergyVictron Orion-TR DC-DC Converter - 24 VDC to 12 VDC - 20AMP Isolated [ORI241224110]
Code: ORA-82876Brand: Victron EnergyLow Stock — Only 6 LeftRegular price $113.90Sale price $113.90 Regular price $134.00Unit price perSale: $20.10 off- Input Voltage Range: 16-35 V
- Under Voltage Shut Down: 14 V
- Under Voltage Restart: 15 V
- Nominal Output Voltage: 12.2 V
-
Save $35.55
Free Shipping on $114+Regular price $201.45Sale price $201.45 Regular price $237.00Unit price perSale: $35.55 offLow Stock — Only 5 Left
More info
- Input Voltage Range: 20-35 V
- Under Voltage Shut Down: 14 V
- Under Voltage Restart: 15 V
- Nominal Output Voltage: 12.2 V
- Output Voltage Adjust Range: 10-15 V
- Output Voltage Tolerance: +/- 0,2 V
- Output Noise: 2 mV rms
- Cont. Output Current at Nominal Output Voltage and 40 Degrees C: 30 A
- Maximum Output Current (10 S) at Nominal Output Voltage: 45 A
- Short Circuit Output Current: 60 A
- Cont. Output Power at 25 Degrees C: 430 W
- Cont. Output Power at 40 Degrees C: 360 W
- Efficiency: 88 %
- No Load Input Current (2): < 100 mA
- Current Consumption: < 200uA when disabled via its remote port
- Galvanic Isolation: 200 VDC between input, output, and case
- Operating Temperature Range: -20 to +55 Degrees C (derate 3 % per °C above 40 °C)
- Humidity: Max. 95 % non-condensing
- DC Connection: Screw terminals
- Maximum Cable Cross-Section: 16 mm² AWG6
- Weight: 1.3 kg (3 lb)
- Dimensions (H x W x D): 130 x 186 x 70 mm (5.1 x 7.3 x 2.8 inch)
- Safety Standards: EN 60950
- Immunity Standards: EN 61000-6-2, EN 61000-6-1, EN 55014-2
- Automotive Directive Standards: ECE R10-5
- Charger Input - Voltage: 24v
- Charger Output - Amps: 30a
- Charger Output Voltage: 12v
- Box Dimensions: 4"H x 5"W x 8"L WT: 4.1 lbs
- UPC: 8719076038849
Victron EnergyVictron Orion-TR DC-DC Converter - 24 VDC to 12 VDC - 30AMP Isolated [ORI241240110]
Code: ORA-82877Brand: Victron EnergyLow Stock — Only 5 LeftRegular price $201.45Sale price $201.45 Regular price $237.00Unit price perSale: $35.55 off- Input Voltage Range: 20-35 V
- Under Voltage Shut Down: 14 V
- Under Voltage Restart: 15 V
- Nominal Output Voltage: 12.2 V
-
Free Shipping on $114+Regular price $453.00Sale price $453.00 Regular priceUnit price perLow Stock — Only 1 Left
More info
- Watertight O-ring sealed and EMC gasketed enclosure
- MIL connectors
- ‘Output ON’ and ‘Overload’ LED indicators
- Compact size and easy mounting
- Up to 80V input
- Heavy duty ruggedization with wide temperature range
- Paralleling diodes
- Custom output voltages available
- Two year warranty (parts and labor)
- Charger Input - Voltage: 20-80v
- Charger Output - Amps: 10a
- Charger Output Voltage: 12v
- Box Dimensions: 5"H x 8"W x 10"L WT: 2.05 lbs
Analytic SystemsAnalytic Systems Waterproof IP66 DC Converter 10A, 12V Out 20-80V In,
Code: ORA-77028Brand: Analytic SystemsLow Stock — Only 1 LeftRegular price $453.00Sale price $453.00 Regular priceUnit price per- Watertight O-ring sealed and EMC gasketed enclosure
- MIL connectors
- ‘Output ON’ and ‘Overload’ LED indicators
- Compact size and easy mounting
-
Analytic Systems
Analytic Systems Waterproof IP66 DC Converter 10A, 24V Out, 30-80V
Free Shipping on $114+Regular price $453.00Sale price $453.00 Regular priceUnit price perLow Stock — Only 4 Left
More info
- Watertight O-ring sealed and EMC gasketed enclosure
- MIL connectors
- ‘Output ON’ and ‘Overload’ LED indicators
- Compact size and easy mounting
- Up to 80V input
- Heavy duty ruggedization with wide temperature range
- Paralleling diodes
- Custom output voltages available
- Two year warranty (parts and labor)
- Charger Input - Voltage: 30-80 VDC
- Charger Output - Amps: 10a
- Charger Output Voltage: 32v
- Box Dimensions: 5"H x 8"W x 10"L WT: 2.05 lbs
Analytic SystemsAnalytic Systems Waterproof IP66 DC Converter 10A, 24V Out, 30-80V
Code: ORA-77029Brand: Analytic SystemsLow Stock — Only 4 LeftRegular price $453.00Sale price $453.00 Regular priceUnit price per- Watertight O-ring sealed and EMC gasketed enclosure
- MIL connectors
- ‘Output ON’ and ‘Overload’ LED indicators
- Compact size and easy mounting
-
Save $13.10
Free Shipping on $114+Regular price $52.50Sale price $52.50 Regular price $65.60Unit price perSale: $13.10 offLow Stock — Only 5 Left
More info
- Advanced switchmode design
- Mount in almost any location
- Compact and light weight
- Reverse polarity protection
- High efficiency
- Cycle by cycle current limiting circuit
- Overvoltage protection
- Short circuit protection
- Input: 20-32 VDC
- Output: 13.8 VDC
- Amps: 5 Amps
- Weight: 0.4 (lbs)
- Weight: 0.18 (kg)
- Dimensions: 3.5 x 2.75 x 1.75 (in)
- Dimensions: 8.9 x 7 x 4.4 (cm)
- Warranty: 2 Year Limited
- Earth moving equipment
- Heavy trucks
- Buses
- Marine vehicles
- CB radios
- 12 Volt lighting systems
- AM/FM sound systems
Samlex AmericaSamlex 5A Non-Isolated Step-Down 24VDC-12VDC Converter [SDC-5]
Code: ORA-67247Brand: Samlex AmericaLow Stock — Only 5 LeftRegular price $52.50Sale price $52.50 Regular price $65.60Unit price perSale: $13.10 off- Advanced switchmode design
- Mount in almost any location
- Compact and light weight
- Reverse polarity protection
-
Samlex America
Samlex 100W Fully Isolated DC-DC Converter - 8A - 20-35V Input - 12.5V Output [IDC-100B-12]
Save $44.60
Free Shipping on $114+Regular price $178.80Sale price $178.80 Regular price $223.40Unit price perSale: $44.60 offLow Stock — Only 3 Left
More info
- Fully Isolated
- Short Circuit Protected
- Current Limited
- 2 Year Warranty
- CE Approved
- Input: 20-35 VDC
- Output: 12.5 VDC
- Amps: 8 Amps
- Weight: 1.2 (lbs)
- Weight: 0.54 (kg)
- Dimensions: 6 x 3.5 x 1.9 (in)
- Dimensions: 15.2 x 8.9 x 4.8 (cm)
- Safety: CE
- Warranty: 2 Year Limited
- Earth moving equipment
- Heavy trucks
- Buses
- Marine vehicles
- CB radios
- 12 Volt lighting systems
- AM/FM sound systems
Samlex AmericaSamlex 100W Fully Isolated DC-DC Converter - 8A - 20-35V Input - 12.5V Output [IDC-100B-12]
Code: ORA-67252Brand: Samlex AmericaLow Stock — Only 3 LeftRegular price $178.80Sale price $178.80 Regular price $223.40Unit price perSale: $44.60 off- Fully Isolated
- Short Circuit Protected
- Current Limited
- 2 Year Warranty
-
Free Shipping on $114+Regular price $626.99Sale price $626.99 Regular price $0.00Unit price perLow Stock — Only 3 Left
More info
- An exceptionally effective use of the consumed input current (cos phi) > 0.98!
- Faster charging of batteries, even with when the input current is limited
- Use of top quality components with a long lifespan
- Savings in weight and space
- Fewer installation materials
- Reliable and very stable DC supply
- For 12 and 24 V battery systems
- Parallel switching of multiple units for capacities of 40, 60 or more Amps
- Battery charger and dimmer function
- Adjustable output voltage
- Voltage stabilization for a longer lifespan of halogen lights, etc
- Corrosion-proof aluminium casing
- Shock-proof
- Temperature-powered fan for cooling
- Generates limited heat, so installable almost anywhere
- Fully MasterBus compatible with a MasterBus Serial Interface
- Nominal output voltage: 13.6V
- Output voltage (adjustable with MasterAdjust): 10-15V
- Output voltage dimmer (adjustable with MasterAdjust): 4-13V
- Output voltage stabilization: 2% at extremes of temperatures, load and input
- Output voltage ripple (peak peak): max. 1%
- Max. output power: 300W
- Nominal output power: 300W
- Max. output current: 20A
- Output charge current (3-step mode): 16 A
- Nominal input voltage: 12V
- Input voltage range: 11-16V
- Input voltage range (3-step charge mode): 12-16V
- Lower input set point (adjustable with MasterAdjust): 10V
- Delay lower input set point (adjustable with MasterAdjust): 30 sec.
- Galvanic isolation: yes
- Voltage limited: yes
- Efficiency: > 90% at nom. input voltage, full load; peak 92 %
- Dimmer function: yes, by external momentary switch via fast-on connection, to be activated by DIP switch setting
- Alarm contact: yes (fast-on connector)
- Dimensions, HxWxD: 227 x 154 x 81mm / 8.9" x 6.1" x 3.2"
- Weight: 1.8kg / 4.0lb
- Approvals: CE
- 3-Step charge option: yes (DIP switch settings)
- DC consumption: < 115 mA
- Connections: screw terminals (max. wire size 16 mm² / AWG5)
- Temperature range (ambient temp.): -25 °C to 80 °C, derating > 40 °C -13 °F to 176 °F
- Sound level: < 48 dBA at 1M
- Protection degree: IP21
- Protections: against over load & over temperature
- Cooling: maintenance free vario fans
- MasterBus compatible: yes, in combination with a MasterBus Serial Interface
MastervoltMastervolt Magic 12/12-20 DC Converter [81300400]
Code: ORA-65629Brand: MastervoltLow Stock — Only 3 LeftRegular price $626.99Sale price $626.99 Regular price $0.00Unit price per- An exceptionally effective use of the consumed input current (cos phi) > 0.98!
- Faster charging of batteries, even with when the input current is limited
- Use of top quality components with a long lifespan
- Savings in weight and space
