Victron Energy
Victron Blue Smart IP65 Charger - 6V/12V - 1.1A - 120V NEMA 1-15 Retail (UL 1236) [BPC120134124R]
Save $12.15
Free Shipping on $114+Regular price $68.85Sale price $68.85 Regular price $81.00Unit price perSale: $12.15 offIn Stock
More info
- Input Voltage & Frequency Range: 100 - 250VAC | 45 - 65Hz
- Efficiency: 82%
- Standby Power Consumption: <0,5 W
- Minimum Battery Voltage: Starts charging from down to 0 V
- Charge voltage 'absorption': Normal: 7,2 V | 14,4 V / High: 7,35 V | 14,7 V / Li-ion: 7,1 V | 14,2 V
- Charge Voltage 'float': Normal: 6,9 V | 13,8 V / High: 6,9 V | 13,8 V / Li-ion: Disabled
- Charge Voltage 'storage': Normal: 6,6 V | 13,2 V / High: 6,6 V | 13,2 V / Li-ion: 6,75 V | 13,5 V
- Charge Current: 1.1 A
- Low-Current Mode: 0,5A
- Temperature Compensation (lead-acid batteries only): 8 mV/°C | 16 mV/°C
- Power Supply Mode: Yes
- Back Current Drain: 0,1 Ah/month (140uA)
- Protection: Reverse polarity, Output short circuit, Over-temperature
- Operating Temp. Range: -30 to +50°C (full rated output up to 30°C)
- Humidity (non-condensing): Max 95%
- Charge Algorithm: 7-stage adaptive
- Bluetooth: 4dBm, 2402–2480 MHz
- Battery-Connection: Black and red cable of 1,5 meter
- 230V AC connection: 1.5m cable with CEE 7/16 or AS/NZS 3112 plug
- Protection Category: IP65 (splash and dust proof)
- Weight: 0,4 kg
- Dimensions: 38 x 64 x 153 mm
- Safety: EN 60335-1, EN 60335-2-29, UL 1236
- Emission; EN 55014-1, EN 61000-6-3, EN 61000-3-2
- Immunity: EN 55014-2, EN 61000-6-1, EN 61000-6-2, EN 61000-3-3
Victron EnergyVictron Blue Smart IP65 Charger - 6V/12V - 1.1A - 120V NEMA 1-15 Retail (UL 1236) [BPC120134124R]
Code: ORA-101853Brand: Victron EnergyIn StockRegular price $68.85Sale price $68.85 Regular price $81.00Unit price perSale: $12.15 off- Input Voltage & Frequency Range: 100 - 250VAC | 45 - 65Hz
- Efficiency: 82%
- Standby Power Consumption: <0,5 W
- Minimum Battery Voltage: Starts charging from down to 0 V
-
Free Shipping on $114+Regular price $669.05Sale price $669.05 Regular price $0.00Unit price perLow Stock — Only 9 Left
More info
- Microprocessor-controlled, multistage charging algorithms
- Settings for two and three-stage charging
- Battery-equalization feature
- Settings for flooded, gel, AGM, or lithium-ion batteries
- Equipped with parallel stacking (remote panel required)
- Ability to charge batteries drained to extremely low voltage
- Added quiet mode
- Reverse-battery polarity protection
- Drip-proof design
- DC over-voltage protection
- Over-temperature protection
- Circuit breaker protection
- Bulk: Replaces 70–80% of the battery’s state-of-charge at the fastest possible rate
- Absorption: Replenishes the remaining 20–30% of charge, bringing the battery to a full charge at a slow, safe rate
- Float: Voltage is reduced and held constant to prevent damage and maintain batteries at a full charge for the remaining 20–30% of charge, bringing the battery to a full charge at a slow, safe rate
- Output Current (nominal): 40 A
- Output Voltage (nominal, depending on settings): Charge 14.2–15.5; Float 13.4–13.8 Vdc; 16 V
- DC Output Connections: Three
- AC Input Voltage: 90–265 Vac; 47–63 Hz 120 Vac, 230 Vac, 240 Vac nominal
- Temperature Compensation: Three settings
- Charger Efficiency: > 80%
- Battery Type: Gel, Flooded, AGM, LiFePO4
- Minimum Recommended Battery Bank Size: 80 Ah
- Operating Temperature Range: 0–60°C (32–140°F)
- Storage Temperature -40–80°C (-40–176°F)
- Battery Connection: Three positive terminals and one negative terminal
- Dimensions (H x W x L): 70 x 170 x 250 mm (2.8 x 6.7 x 9.8”)
- Weight 2.2 kg (4.8 lb)
- Charger Output - Amps: 40a
- Charger Output Voltage: 12v
- Charging Banks: 3
- Portable: No
- Box Dimensions: 6"H x 11"W x 13"L WT: 6.19 lbs
- UPC: 715535920814
XantrexXantrex TRUEcharge3 40A 3 Bank Battery Charger - 12V [804-1240-10]
Code: ORA-101671Brand: XantrexLow Stock — Only 9 LeftRegular price $669.05Sale price $669.05 Regular price $0.00Unit price per- Microprocessor-controlled, multistage charging algorithms
- Settings for two and three-stage charging
- Battery-equalization feature
- Settings for flooded, gel, AGM, or lithium-ion batteries
-
Victron Energy
Victron Lynx Smart BMS 1000 Battery Management System f/Lithium Smart Batteries [LYN034170210]
Save $207.90
Free Shipping on $114+Regular price $1,178.10Sale price $1,178.10 Regular price $1,386.00Unit price perSale: $207.90 offIn Stock
More info
- Lynx Distributor with 2 fused paralleled lithium-ion smart batteries.
- Lynx Smart BMS with BMS, contactor, and battery monitor
- A second Lynx distributor provides fused connections for inverter/charger(s), loads and chargers (additional modules can be added if more connections are needed)
- A Cerbo GX (or other GX device) to read out the Lynx Smart BMS and Lynx Distributor data.
- Battery Voltage Range: 9 – 60 VDC
- Maximum Input Voltage: 75 VDC
- Supported System Voltages: 12, 24, or 48 V
- Reverse Polarity Protection: No
- Main Safety Contactor Continuous Current Rating: 1000 A continuous
- Main Safety Contactor Peak Current Rating: 1200 A for 5 minutes
- Power Consumption OFF Mode: 0.3 mA for all system voltages
- Power Consumption in Standby Mode: Approximately 0.6 W (50 mA at 12 V)
- Power Consumption in ON Mode: Approx. 2.6 W (217 mA at 12 V) depending on the state of the relays
- Approximately 4.2 W (350 mA at 12 V) depending on the state of the relays
- Minimum Load Resistance for Pre-Charging: 10 Ω and above for 12 V systems, 20 Ω and above for 24 V and 48 V systems
- AUX Output Maximum Current Rating: 1.1 A continuous, protected by resettable fuse
- Allow-to-Charge Port Maximum Current Rating: 0.5 A at 60 VDC, protected by a resettable fuse
- Allow-to-Discharge Port Maximum Current Rating: 0.5 A at 60VDC, protected by a resettable fuse
- Alarm Relay (SPDT) Maximum current Rating: 2 A at 60 VDC
- Busbar: M10 (Torque: 17 Nm)
- VE.Can: RJ45
- I/O: Removable multi-connector with screw terminals
- Enclosure Material: ABS
- Enclosure Dimensions (h x w x d): 230 x 180 x 100 mm
- Unit Weight: 2.7 kg
- Busbar Material: Tinned copper
- Busbar Dimensions (h x w): 8 x 30 mm
- Operating Temperature Range: -40 °C to +60 °C
- Storage Temperature Range: -40 °C to +60 °C
- Humidity Max.: 95 % (non-condensing)
- Protection Class: IP22
- Safety: EN-IEC 63000:2018
- EMC: EN-IEC 61000-6-3:2007/A1:2011/AC:2012
- QMS: NEN-EN-ISO 9001:2015
Victron EnergyVictron Lynx Smart BMS 1000 Battery Management System f/Lithium Smart Batteries [LYN034170210]
Code: ORA-101855Brand: Victron EnergyIn StockRegular price $1,178.10Sale price $1,178.10 Regular price $1,386.00Unit price perSale: $207.90 off- Lynx Distributor with 2 fused paralleled lithium-ion smart batteries.
- Lynx Smart BMS with BMS, contactor, and battery monitor
- A Cerbo GX (or other GX device) to read out the Lynx Smart BMS and Lynx...
- Battery Voltage Range: 9 – 60 VDC
-
Free Shipping on $114+ Authorized KICKER DealerRegular price $349.99Sale price $349.99 Regular priceUnit price perIn Stock
More info
- Full-spec OFC cable
- Tinned in anti-corrosive nickel
- Flexible jacketing for easy installation
- Meets the highest industry standards for marine use
- Color: Yellow
- Gauge: 4 AWG
- Length (Feet): 100'
- Box Dimensions: 9"H x 12"W x 12"L WT: 22.2 lbs
- UPC: 713034013891
KICKERKICKER KMWPY4100 100' 4AWG Power Wire - Yellow [47KMWPY4100]
Code: ORA-102026Brand: KICKERIn StockRegular price $349.99Sale price $349.99 Regular priceUnit price per- Full-spec OFC cable
- Tinned in anti-corrosive nickel
- Flexible jacketing for easy installation
- Meets the highest industry standards for marine use
-
Free Shipping on $114+ Authorized KICKER DealerRegular price $89.99Sale price $89.99 Regular priceUnit price perIn Stock
More info
- Full-spec OFC cable
- Tinned in anti-corrosive nickel
- Flexible jacketing for easy installation
- Meets the highest industry standards for marine use
- Color: Red
- Gauge: 4 AWG
- Length (Feet): 20'
- Box Dimensions: 2"H x 7"W x 7"L WT: 3.6 lbs
- UPC: 713034013785
KICKERKICKER KMWPR420 20' 4AWG Power Wire - Red [47KMWPR420]
Code: ORA-102027Brand: KICKERIn StockRegular price $89.99Sale price $89.99 Regular priceUnit price per- Full-spec OFC cable
- Tinned in anti-corrosive nickel
- Flexible jacketing for easy installation
- Meets the highest industry standards for marine use
-
Free Shipping on $114+ Authorized KICKER DealerRegular price $329.99Sale price $329.99 Regular priceUnit price perIn Stock
More info
- Full-spec OFC cable
- Tinned in anti-corrosive nickel
- Flexible jacketing for easy installation
- Meets the highest industry standards for marine use
- Color: Red
- Gauge: 8 AWG
- Length (Feet): 200'
- Box Dimensions: 9"H x 12"W x 12"L WT: 17.8 lbs
- UPC: 713034013877
KICKERKICKER KMWPR8200 200' 8AWG Power Wire - Red [47KMWPR8200]
Code: ORA-102029Brand: KICKERIn StockRegular price $329.99Sale price $329.99 Regular priceUnit price per- Full-spec OFC cable
- Tinned in anti-corrosive nickel
- Flexible jacketing for easy installation
- Meets the highest industry standards for marine use
-
Free Shipping on $114+ Authorized KICKER DealerRegular price $349.99Sale price $349.99 Regular priceUnit price perIn Stock
More info
- Full-spec OFC cable
- Tinned in anti-corrosive nickel
- Flexible jacketing for easy installation
- Meets the highest industry standards for marine use
- Color: Red
- Gauge: 4 AWG
- Length (Feet): 100'
- Box Dimensions: 9"H x 12"W x 12"L WT: 22.6 lbs
- UPC: 713034013662
KICKERKICKER KMWPR4100 100' 4AWG Power Wire - Red [47KMWPR4100]
Code: ORA-102025Brand: KICKERIn StockRegular price $349.99Sale price $349.99 Regular priceUnit price per- Full-spec OFC cable
- Tinned in anti-corrosive nickel
- Flexible jacketing for easy installation
- Meets the highest industry standards for marine use
-
Free Shipping on $114+Regular price $1,160.38Sale price $1,160.38 Regular price $0.00Unit price perLow Stock — Only 7 Left
More info
- Microprocessor-controlled, multistage charging algorithms
- Settings for two and three-stage charging
- Battery-equalization feature
- Settings for flooded, gel, AGM, or lithium-ion batteries
- Equipped with parallel stacking (remote panel required)
- Ability to charge batteries drained to extremely low voltage
- Added quiet mode
- Reverse-battery polarity protection
- Drip-proof design
- DC over-voltage protection
- Over-temperature protection
- Circuit breaker protection
- Bulk: Replaces 70–80% of the battery’s state-of-charge at the fastest possible rate
- Absorption: Replenishes the remaining 20–30% of charge, bringing the battery to a full charge at a slow, safe rate
- Float: Voltage is reduced and held constant to prevent damage and maintain batteries at a full charge for the remaining 20–30% of charge, bringing the battery to a full charge at a slow, safe rate
- Output Current (nominal): 60 A
- Output Voltage (nominal, depending on settings): Charge 14.2–15.5; Float 13.4–13.8 Vdc; 16 V
- DC Output Connections: Three
- AC Input Voltage: 90–265 Vac; 47–63 Hz 120 Vac, 230 Vac, 240 Vac nominal
- Temperature Compensation: Three settings
- Charger Efficiency: > 80%
- Battery Type: Gel, Flooded, AGM, LiFePO4
- Minimum Recommended Battery Bank Size: 120 Ah
- Operating Temperature Range: 0–60°C (32–140°F)
- Storage Temperature -40–80°C (-40–176°F)
- Battery Connection: Three positive terminals and one negative terminal
- Dimensions (H x W x L): 90 x 170 x 340 mm (3.5 x 6.7 x 13.4”)
- Weight 4.5 kg (9.9 lb)
- Charger Output - Amps: 60a
- Charger Output Voltage: 12v
- Charging Banks: 3
- Portable: No
- Box Dimensions: 6"H x 11"W x 17"L WT: 8.95 lbs
- UPC: 715535920852
XantrexXantrex TRUEcharge3 60A 3 Bank Battery Charger - 12V [804-1260-10]
Code: ORA-101672Brand: XantrexLow Stock — Only 7 LeftRegular price $1,160.38Sale price $1,160.38 Regular price $0.00Unit price per- Microprocessor-controlled, multistage charging algorithms
- Settings for two and three-stage charging
- Battery-equalization feature
- Settings for flooded, gel, AGM, or lithium-ion batteries
-
Victron Energy
Victron MagCode Power Port f/Blue Smart IP65 Charger - 12V - 15 Amp Max (Requires Power Clip) [BPC900520014]
Save $8.25
Free Shipping on $114+Regular price $46.75Sale price $46.75 Regular price $55.00Unit price perSale: $8.25 offIn Stock
More info
- Volt: 12V
- Max Amp: 15
Victron EnergyVictron MagCode Power Port f/Blue Smart IP65 Charger - 12V - 15 Amp Max (Requires Power Clip) [BPC900520014]
Code: ORA-101852Brand: Victron EnergyIn StockRegular price $46.75Sale price $46.75 Regular price $55.00Unit price perSale: $8.25 off- Volt: 12V
- Max Amp: 15
-
Victron Energy
Victron Outdoor Antenna f/GX LTE 4G-A [GSM900100400]
Save $5.25
Free Shipping on $114+Regular price $29.75Sale price $29.75 Regular price $35.00Unit price perSale: $5.25 offLow Stock — Only 7 Left
More info
- Mounting Option: Screw mount
- Cable Type: RG-316
- Cable Length: 3.0 m
- Connector: SMA male straight
- Frequencies: 800/900/1800/1900/2100 MHz
- Signal Gain: 3 dBi
Victron EnergyVictron Outdoor Antenna f/GX LTE 4G-A [GSM900100400]
Code: ORA-100482Brand: Victron EnergyLow Stock — Only 7 LeftRegular price $29.75Sale price $29.75 Regular price $35.00Unit price perSale: $5.25 off- Mounting Option: Screw mount
- Cable Type: RG-316
- Cable Length: 3.0 m
- Connector: SMA male straight
-
Free Shipping on $114+Regular price $12.25Sale price $12.25 Regular price $0.00Unit price perLow Stock — Only 10 Left
More info
- Designed with D-flats to prevent gauges from spinning, the assembly is held in place by the socket/meter nut for a clean, finished look
- Constructed of UV-resistant injection-molded nylon
- Color: White
- Face Plate Outer diameter: 3-3/4 in.
- Face Plate Inner Diameter: 1-3/16 in.
- Face Plate Thickness: 3/16 in.
- Height: 3-3/8 in.
- Washer Inner Diameter: 1-1/16 in.
- Washer Thickness: 1/8 in.
- Weight: 0.06
Sea-Dog84470Sea-Dog 4" Gauge Power Socket Adapter Mounting Plate - White [426104-1]
Code: ORA-100583Brand: Sea-DogLow Stock — Only 10 LeftRegular price $12.25Sale price $12.25 Regular price $0.00Unit price per- Designed with D-flats to prevent gauges from spinning, the assembly is held in place by the...
- Constructed of UV-resistant injection-molded nylon
- Color: White
- Face Plate Outer diameter: 3-3/4 in.
-
Victron Energy
Victron Active GPS Antenna f/GX LTE Modem [GSM900200100]
Save $5.25
Free Shipping on $114+Regular price $29.75Sale price $29.75 Regular price $35.00Unit price perSale: $5.25 offLow Stock — Only 9 Left
More info
- Mounting Option: Magnet
- Cable Type: RG-74
- Cable Length: 3.0 m
- Connector: SMA male straight
- Frequencies: 1575.42 MHz
- Signal Gain: 50 Ω
Victron EnergyVictron Active GPS Antenna f/GX LTE Modem [GSM900200100]
Code: ORA-100481Brand: Victron EnergyLow Stock — Only 9 LeftRegular price $29.75Sale price $29.75 Regular price $35.00Unit price perSale: $5.25 off- Mounting Option: Magnet
- Cable Type: RG-74
- Cable Length: 3.0 m
- Connector: SMA male straight
-
Free Shipping on $114+Regular price $4.95Sale price $4.95 Regular price $0.00Unit price perIn Stock
More info
- Distance Between Holes (Length): 3-1/2 in.
- Distance Between Holes (Width): 1 in.
- Diameter: 1-1/8 in.
- Weight: 0.05 lb.
Sea-DogSea-Dog Two Socket Mounting Plate Only [426501]
Code: ORA-100563Brand: Sea-DogIn StockRegular price $4.95Sale price $4.95 Regular price $0.00Unit price per- Distance Between Holes (Length): 3-1/2 in.
- Distance Between Holes (Width): 1 in.
- Diameter: 1-1/8 in.
- Weight: 0.05 lb.
-
Free Shipping on $114+Regular price $29.99Sale price $29.99 Regular priceUnit price perIn Stock
More info
- 120 -150W max power 12V system only
- IPX4 waterproof
- Compact footprint
- Marine-grade materials
- Nickel-Plated copper alloy internal contacts
- UV resistant
- 316 stainless hinge and springs
ScanstrutScanstrut Flip Pro 12V Power Socket [SC-12V-F1]
Code: ORA-100494Brand: ScanstrutIn StockRegular price $29.99Sale price $29.99 Regular priceUnit price per- 120 -150W max power 12V system only
- IPX4 waterproof
- Compact footprint
- Marine-grade materials
-
Save $35.25
Free Shipping on $114+Regular price $199.75Sale price $199.75 Regular price $235.00Unit price perSale: $35.25 offLow Stock — Only 5 Left
More info
- Region: For North America
- Used Module: SIMCom, SIM7600A
- Supported LTE Bands: 2, 4, 12
- Supply Voltage Range: 8 - 70VDC
- Power Draw: 2.5W while 2G/3G/4G data transfer / <1.0W in idle mode / +0.4W if GPS is enabled
- Operating Temperature Range: -40 +50°C (-40 - 120°F)
- Power Cable (Included): 1.4m cable with inline fuse holder, terminal block, and 10mm ring terminals
- Inline Fuse (included): T3.15A250V
- USB Communication Port: Fixed 1.0m cable with USB-A connector (connects to the GX device)
- LTE Antenna Connector: Type SMA Female (optional 4G outdoor antenna GSM900100400)
- GPS Antenna Connector: Type SMA Female (optional GPS antenna GSM900200100)
- GNSS: GPS/Beidou/GLONASS/GALILEO/QZSS
- SIM Card: Regular Mini SIM (supports both 1.8V and 3V)
- Data Transmission (max. Download/Upload) LTE Cat-1: 10 Mbps / 5 Mbps
- Data Transmission (max. Download/Upload) 3G (HSPA+): 42 Mbps / 5.76 Mbps
- Data Transmission (max. Download/Upload) 2G (EDGE): 236.8 Kbps / 236.8 Kbps
- Data Transmission (max. Download/Upload) 2G (GPRS): 85.6 Kbps / 85.6 Kbps
- Status Indicator: Blue LED
- Dimensions (l x w x h): 106 × 42.5 × 22mm
- Weight: 0.08kg (0.177lbs)
- Wire Gauge (power cable): 0.5..1.5mm2 / AWG 28..16 or use supplied power cable
- Recommended Fuse Size: 500mA @ 12V / 250mA @ 24V / 100mA @ 48V or use supplied inline fuse
- GX LTE 4G (with integrated USB cable)
- GSM 2G/3G/4G mini-rod antenna (for indoor use)
- DC power cable (with inline fuse and terminal block)
- Safety: EN 60335-1 / EN 60335-2-29 / EN 62368-1
- Emission / Immunity: ECE R10-5
- QM: EN 9001:2015
Victron EnergyVictron GX LTE 4G-A Cellular Modem f/GX Devices - North America Only [GSM100200400]
Code: ORA-100480Brand: Victron EnergyLow Stock — Only 5 LeftRegular price $199.75Sale price $199.75 Regular price $235.00Unit price perSale: $35.25 off- Region: For North America
- Used Module: SIMCom, SIM7600A
- Supported LTE Bands: 2, 4, 12
- Supply Voltage Range: 8 - 70VDC
-
Free Shipping on $114+Regular price $12.25Sale price $12.25 Regular priceUnit price perLow Stock — Only 7 Left
More info
- Designed with D-flats to prevent gauges from spinning, the assembly is held in place by the socket/meter nut for a clean, finished look
- Constructed of UV-resistant injection-molded nylon
- Color: Black
- Face Plate Outer diameter: 3-3/4 in.
- Face Plate Inner Diameter: 1-3/16 in.
- Face Plate Thickness: 3/16 in.
- Height: 3-3/8 in.
- Washer Inner Diameter: 1-1/16 in.
- Washer Thickness: 1/8 in.
- Weight: 0.06
Sea-DogSea-Dog 4" Gauge Power Socket Adapter Mounting Plate [426103-1]
Code: ORA-100582Brand: Sea-DogLow Stock — Only 7 LeftRegular price $12.25Sale price $12.25 Regular priceUnit price per- Designed with D-flats to prevent gauges from spinning, the assembly is held in place by the...
- Constructed of UV-resistant injection-molded nylon
- Color: Black
- Face Plate Outer diameter: 3-3/4 in.
-
Free Shipping on $114+Regular price $96.99Sale price $96.99 Regular priceUnit price perIn Stock
More info
- Universal fit for any USB-C connectors
- Fast charge (60W max) up to 2 devices at a time
- IPX4 waterproof with the cover closed
- UV resistant
- 316 stainless steel hinge and spring
- 120 -150W max power (12V system only)
- Input voltage: 10-30V DC (12/24V System)
- Input current Max: 6A (10A fuse recommended)
- To maximize charge performance, use the cable supplied with your tablet, phone, etc. (C to C, or C-lightning)
- Phones charge at the same speed on either a 12 or 24V system, but a 24V system must be used to get the full 60W output suitable for laptops
ScanstrutScanstrut Flip Pro Multi - Dual USB-C 12V Power Socket [SC-MULTI-F1]
Code: ORA-100091Brand: ScanstrutIn StockRegular price $96.99Sale price $96.99 Regular priceUnit price per- Universal fit for any USB-C connectors
- Fast charge (60W max) up to 2 devices at a time
- IPX4 waterproof with the cover closed
- UV resistant
-
Free Shipping on $114+Regular price $249.00Sale price $249.00 Regular priceUnit price perLow Stock — Only 1 Left
More info
- Onboard internal fuse block, great for john boats and kayaks
- Anderson battery plug with terminals and four #8 FH mounting fasteners included
- 12-24V. 50A
- Length (inch): 6-1/4"
- Height (inch): 3-1/8"
- Width (inch): 5-9/16"
- Volts: 12-24
- Total Output (Amps): 50A
- Weight: 1.70 lb.
- Color: Black box
Sea-DogSea-Dog Power Box Battery Switch [422737-3]
Code: ORA-100302Brand: Sea-DogLow Stock — Only 1 LeftRegular price $249.00Sale price $249.00 Regular priceUnit price per- Onboard internal fuse block, great for john boats and kayaks
- Anderson battery plug with terminals and four #8 FH mounting fasteners included
- 12-24V. 50A
- Length (inch): 6-1/4"
-
Free Shipping on $114+Regular price $50.95Sale price $50.95 Regular price $0.00Unit price perLow Stock — Only 2 Left
More info
- Includes two 1/4"-20 stainless steel stud terminals and six #8-32 stainless steel screw terminals per buss
- Installs with four #8 FH fasteners (included)
- 48VDC, 150A per buss; 300VAC, 150A per buss
- CE and RoHS compliant
- Terminals: 12
- Length (inch): 5-1/2"
- Width (inch): 2-3/4"
- Depth (inch): 1-11/16"
- Max. Amps: 150
- Fastener: #8 FH
- Weight: 0.59 lb.
Sea-DogSea-Dog Dual Buss Bar w/Cover - 12 Terminals [426693-3]
Code: ORA-100308Brand: Sea-DogLow Stock — Only 2 LeftRegular price $50.95Sale price $50.95 Regular price $0.00Unit price per- Includes two 1/4"-20 stainless steel stud terminals and six #8-32 stainless steel screw terminals per buss
- Installs with four #8 FH fasteners (included)
- 48VDC, 150A per buss; 300VAC, 150A per buss
- CE and RoHS compliant
-
Victron Energy
Victron Orion-TR Smart Non-Isolated DC-DC Converter - 24 VDC to 24 VDC - 400W - 17AMP [ORI242440140]
Save $37.95
Free Shipping on $114+Regular price $215.05Sale price $215.05 Regular price $253.00Unit price perSale: $37.95 offLow Stock — Only 7 Left
More info
- Any Bluetooth-enabled smartphone, tablet, or other device can be used to monitor, change settings, and update the charger when new software features become available.
- Instant Readout: The VictronConnect App can display key data, including warnings and alarms, on the device list page without the need to connect to the product.
- Battery charge algorithm (configurable) or fixed output.
- Smart alternator compatibility: engine running detection mechanism.
- For lithium batteries, the absorption time is fixed (the default is 2 hours).
- Alternatively, a fixed output voltage can be chosen.
- Input Voltage Range: 20-35 V
- Under Voltage Shut Down: 14 V
- Under Voltage Restart: 15 V
- Nominal Output Voltage: 24.2 V
- Output Voltage Adjust Range: 20-30 V
- Output Voltage Tolerance: +/- 0,2 V
- Output Noise: 2 mV rms
- Cont. Output Current at Nominal Output Voltage and 40 Degrees C: 17 A
- Maximum Output Current (10 S) at Nominal Output Voltage: 25 A
- Short Circuit Output Current: 40A
- Cont. Output Power at 25 Degrees C: 480 W
- Cont. Output Power at 40 Degrees C: 400 W
- Efficiency: 89%
- No Load Input Current (2): < 80 mA
- Standby Current: Less than 1 mA
- Galvanic Isolation: 200 VDC between input, output, and case
- Operating Temperature Range: -20 to +55 Degrees C (derate 3 % per °C above 40 °C)
- Humidity: Max. 95 % non-condensing
- DC Connection: Screw terminals
- Maximum Cable Cross-Section: 16 mm² AWG6
- Weight: 1,6 kg (3.5 lb)
- Dimensions (H x W x D): 130 x 186 x 70 mm (5.1 x 7.3 x 2.8 inch)
- Protection Category: IP43 (electronic components), IP22 (connection area)
- Safety Standards: EN 60950
- Immunity Standards: EN 61000-6-2, EN 61000-6-1, EN 55014-2
- Automotive Directive Standards: ECE R10-5
- Charger Input - Voltage: 24v
- Charger Output - Amps: 17a
- Charger Output Voltage: 24v
- Charging Banks: 1
- Portable: No
- Box Dimensions: 4"H x 5"W x 8"L WT: 3.5 lbs
- UPC: 8719076048985
Victron EnergyVictron Orion-TR Smart Non-Isolated DC-DC Converter - 24 VDC to 24 VDC - 400W - 17AMP [ORI242440140]
Code: ORA-100042Brand: Victron EnergyLow Stock — Only 7 LeftRegular price $215.05Sale price $215.05 Regular price $253.00Unit price perSale: $37.95 off- Battery charge algorithm (configurable) or fixed output.
- Smart alternator compatibility: engine running detection mechanism.
- For lithium batteries, the absorption time is fixed (the default is 2 hours).
- Alternatively, a fixed output voltage can be chosen.
-
Save $230.85
Free Shipping on $114+Regular price $1,308.15Sale price $1,308.15 Regular price $1,539.00Unit price perSale: $230.85 offIn Stock
More info
- PowerControl & PowerAssist: Yes (on L1 input)
- Transfer Switch: 50 A
- Maximum AC Input Current: 50A (each leg)
- DC Input Voltage Range: 19-33V
- Output When in Inverter Mode: Output voltage: 120 Vac ± 2% / Frequency: 60 Hz ± 0.1% (1)
- Cont. Output Power at 25°C: 3000 VA
- Cont. Output Power at 25°C: 2400 W
- Cont. Output Power at 40°C: 2200 W
- Cont. Output Power at 65°C: 1700 W
- Maximum Apparent Feed-in Power: 2500 VA
- Peak Power: 5500 W
- Maximum Efficiency: 94%
- Zero Load Power: 11W
- Zero Load Power in AES Mode: 8W
- Zero Load Power in Search Mode: 4W
- AC Input: Split-phase: 180-280Vac 45 – 65Hz / Single-phase: 90-140Vac 45 – 65Hz
- Charge Voltage 'Absorption': 28.8 V
- Charge Voltage 'Float': 27.6 V
- Storage Mode: 26.4 V
- Maximum Battery Charge Current: 70 A
- Battery Temperature Sensor: Yes
- Auxiliary Output: 50 A (each leg)
- External AC current Sensor (optional): 100A
- Programmable Relay: Yes
- Protection: a – g
- VE.Bus Communication Port: For parallel and three-phase operation, remote monitoring and system integration
- General Purpose com. Port: Yes, 2x
- Remote On-Off: Yes
- Operating Temperature Range: -40 to +65°C (-40 -150°F) Fan assisted cooling
- Humidity (non-condensing): Max 95%
- Material & Color: Steel, blue RAL 5012
- Protection Category: IP22
- Battery-Connection: 2 M8 bolts
- 120/240 V AC-Connection: Screw terminals 21 mm² (4 AWG)
- Weight: 22.5 kg / (50lb)
- Dimensions (hxwxd): 579 x 319 x 168 mm / (23 x 13 x 7 inch)
- Safety: EN-IEC 60335-1, EN-IEC 60335-2-29
- Emission, Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3
- Can be adjusted to 50 Hz
- Protection key: Output short circuit, overload, battery voltage too high, battery voltage too low, temperature too high, 120Vac on inverter output, input voltage ripple too high
- Non-linear load, crest factor 3:1.
- Up to 75-degrees F / 25-degrees C ambient temperature
- Switches off when no external AC source is available.
- Programmable Relay That Can for Example Be Set for General Alarm or DC under Voltage or Genset Start/Stop Function: AC rating: 120Vac / 4A / DC rating: 4A up to 35dc, 1A up to 60Vdc
- Use, for example, to communicate with a lithium battery BMS
- Charger Input - Voltage: 120VAC
- Charger Output - Amps: 70A
- Charger Output Voltage: 24V
- Charging Banks: 2x120VAC
- Inverter Cont. Output Wattage: 3000VA / 2400W
- Inverter Input Voltage: 24VDC
- Inverter Output Voltage: 120VAC
- Outlet Qty: None
- Box Dimensions: 11"H x 17"W x 27"L WT: 55.9 lbs
- UPC: 8719076057376
Victron EnergyVictron Quattro-II - 24/3000 - 70-50/50 - 2X 120V [QUA242305130]
Code: ORA-100131Brand: Victron EnergyIn StockRegular price $1,308.15Sale price $1,308.15 Regular price $1,539.00Unit price perSale: $230.85 off- PowerControl & PowerAssist: Yes (on L1 input)
- Transfer Switch: 50 A
- Maximum AC Input Current: 50A (each leg)
- DC Input Voltage Range: 19-33V
-
Free Shipping on $114+Regular price $51.52Sale price $51.52 Regular price $0.00Unit price perLow Stock — Only 3 Left
More info
- 20A fuse holder
- Constructed of injection molded ABS
- Installs with a gasket and four RH fasteners (included)
- Specifications:
- Length (inch): 4-11/16"
- Width (inch): 2-3/8"
- Width Between Fasteners (inch): 1-1/2"
- Length Between Fasteners (inch): 3-7/8"
- Volts: 12
- Weight: 0.33 lb.
- Color: Black
- Color: Black
- Box Dimensions: 3"H x 4"W x 7"L WT: 0.4 lbs
- UPC: 035514423878
Sea-DogSea-Dog Bilge Pump Water Alarm Panel w/Switch [423037-1]
Code: ORA-100303Brand: Sea-DogLow Stock — Only 3 LeftRegular price $51.52Sale price $51.52 Regular price $0.00Unit price per- 20A fuse holder
- Constructed of injection molded ABS
- Installs with a gasket and four RH fasteners (included)
- Specifications:
-
Free Shipping on $114+Regular price $54.95Sale price $54.95 Regular price $0.00Unit price perLow Stock — Only 8 Left
More info
- Includes two 5/16"-18 stainless steel stud terminals and six #10-32 stainless steel screw terminals
- Installs with four #8 FH fasteners (included)
- 48VDC, 300A; 300VAC, 300A maximum
- CE and RoHS compliant
- Terminals: 6
- Length (inch): 5-1/2"
- Width (inch): 2-3/4"
- Depth (inch): 1-11/16"
- Max. Amps: 300
- Fastener: #8 FH
- Weight: 0.68 lb.
Sea-DogSea-Dog Buss Bar w/Cover - 6 Terminals [426692-3]
Code: ORA-100307Brand: Sea-DogLow Stock — Only 8 LeftRegular price $54.95Sale price $54.95 Regular price $0.00Unit price per- Includes two 5/16"-18 stainless steel stud terminals and six #10-32 stainless steel screw terminals
- Installs with four #8 FH fasteners (included)
- 48VDC, 300A; 300VAC, 300A maximum
- CE and RoHS compliant
-
Save $243.00
Free Shipping on $114+Regular price $1,377.00Sale price $1,377.00 Regular price $1,620.00Unit price perSale: $243.00 offIn Stock
More info
- PowerControl & PowerAssist: Yes (on L1 input)
- Transfer Switch: 50 A
- Maximum AC Input Current: 50A (each leg)
- DC Input Voltage Range: 9.5-17V
- Output When in Inverter Mode: Output voltage: 120 Vac ± 2% / Frequency: 60 Hz ± 0.1% (1)
- Cont. Output Power at 25°C: 3000 VA
- Cont. Output Power at 25°C: 2400 W
- Cont. Output Power at 40°C: 2200 W
- Cont. Output Power at 65°C: 1700 W
- Maximum Apparent Feed-in Power: 2500 VA
- Peak Power: 5500 W
- Maximum Efficiency: 93%
- Zero Load Power: 15W
- Zero Load Power in AES Mode: 10W
- Zero Load Power in Search Mode: 4W
- AC Input: Split-phase: 180-280Vac 45 – 65Hz / Single-phase: 90-140Vac 45 – 65Hz
- Charge Voltage 'Absorption': 14.4V
- Charge Voltage 'Float': 13.8V
- Storage Mode: 13.2V
- Maximum Battery Charge Current: 120A
- Battery Temperature Sensor: Yes
- Auxiliary Output: 50 A (each leg)
- External AC current Sensor (optional): 100A
- Programmable Relay: Yes
- Protection: a – g
- VE.Bus Communication Port: For parallel and three-phase operation, remote monitoring and system integration
- General Purpose com. Port: Yes, 2x
- Remote On-Off: Yes
- Operating Temperature Range: -40 to +65°C (-40 -150°F) Fan assisted cooling
- Humidity (non-condensing): Max 95%
- Material & Color: Steel, blue RAL 5012
- Protection Category: IP22
- Battery-Connection: 2x2 M8 bolts
- 120/240 V AC-Connection: Screw terminals 21 mm² (4 AWG)
- Weight: 32.8 kg / (52 lb)
- Dimensions (hxwxd): 579 x 319 x 168 mm / (23 x 13 x 7 inch)
- Safety: EN-IEC 60335-1, EN-IEC 60335-2-29
- Emission, Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3
- Can be adjusted to 50 Hz
- Protection key: Output short circuit, overload, battery voltage too high, battery voltage too low, temperature too high, 120Vac on inverter output, input voltage ripple too high
- Non-linear load, crest factor 3:1.
- Up to 75-degrees F / 25-degrees C ambient temperature
- Switches off when no external AC source is available.
- Programmable Relay That Can for Example Be Set for General Alarm or DC under Voltage or Genset Start/Stop Function: AC rating: 120Vac / 4A / DC rating: 4A up to 35dc, 1A up to 60Vdc
- Use, for example, to communicate with a lithium battery BMS
- Charger Input - Voltage: 120VAC
- Charger Output - Amps: 50A
- Charger Output Voltage: 14VDC
- Charging Banks: 2
- Inverter Cont. Output Wattage: 3000VA / 2400W
- Inverter Input Voltage: 9.5 - 17VDC
- Inverter Output Voltage: 120VAC
- Outlet Qty: None
- Box Dimensions: 11"H x 17"W x 27"L WT: 60 lbs
- UPC: 8719076057369
Victron EnergyVictron Quattro-II - 12/3000 - 120-50/50 - 2X 120V [QUA122305130]
Code: ORA-100132Brand: Victron EnergyIn StockRegular price $1,377.00Sale price $1,377.00 Regular price $1,620.00Unit price perSale: $243.00 off- PowerControl & PowerAssist: Yes (on L1 input)
- Transfer Switch: 50 A
- Maximum AC Input Current: 50A (each leg)
- DC Input Voltage Range: 9.5-17V
